Q1: What is the iBX-992 SWIR camera used for?
A: It is designed for industrial SWIR imaging applications, including semiconductor inspection, material analysis, moisture detection, and scientific research.
Q2: What is the spectral range of this camera?
A: The camera operates in the 400–1700nm SWIR range, with an optional extension up to 1800nm using filters.
Q3: What is the maximum frame rate?
A: It delivers up to 165fps at 2560×2048 resolution, enabling high-speed imaging for dynamic inspection tasks.
Q4: Does the camera support global shutter?
A: Yes, it uses a global shutter sensor, ensuring distortion-free imaging of fast-moving objects.
Q5: What interface options are available?
A: The iBX-992 supports USB 3.0, GigE Vision, and CameraLink interfaces, allowing flexible system integration.
Q6: What cooling system is used?
A: It features TEC (Thermoelectric Cooling) that stabilizes the sensor temperature up to 25°C below ambient.
Q7: Is it suitable for low-light or invisible imaging?
A: Yes, the SWIR range allows detection of features invisible to the human eye, ideal for defect and material inspection.
Q8: What industries use this camera most?
A: It is widely used in semiconductor, electronics, photovoltaics, food inspection, and scientific imaging industries.
Estimated Delivery Time
Ship To Detecting...
?
Shipping dates are estimates and subject to change. By ordering, you accept possible schedule adjustments. For urgent orders, please confirm with us before purchasing. Post-order cancellations are subject to a 6.4% handling fee.
説明
製品説明
高度な材料検査と科学イメージング向け高速SWIR産業用カメラ
iBX-992シリーズSWIR産業用カメラは、要求の厳しい産業検査、半導体分析、および科学アプリケーション向けに設計された高性能な短波長赤外線イメージングシステムです。
1/1.4インチInGaAsセンサーと400–1700nm（オプションで1800nmまで）のスペクトル応答範囲を備え、可視光および赤外線のイメージングにおいて卓越した感度を実現します。2560 × 2048の解像度と最大165fpsのフレームレートにより、高速移動する検査タスク向けに高速かつ高解像度のキャプチャを提供します。
グローバルシャッター技術、12ビットダイナミックレンジイメージング、および-20°Cから60°Cまでの安定した動作に対応し、iBX-992は過酷な環境下でも正確で歪みのないイメージングを確保します。
USB 3.0、GigE Vision、CameraLinkを含む柔軟な接続オプションにより、異なるマシンビジョンシステムアーキテクチャへの高い適応性を発揮します。統合されたTEC冷却技術により、センサー温度を周囲温度より25°C低く維持し、長期にわたるイメージングの安定性を確保します。
主な特徴
✔ 1/1.4インチ高感度InGaAsセンサー
400–1700nmのSWIRイメージングに最適化されています。
✔ 高解像度2560 × 2048イメージング
精密な検査タスクに細部のディテールを提供します。
✔ 最大165fpsの高速性能
高速移動する産業および科学アプリケーションに最適です。
✔ グローバルシャッター技術
動的なシーンの歪みのないイメージングを確保します。
✔ 複数インターフェース対応
USB 3.0 / GigE Vision / CameraLink互換性。
✔ TEC冷却システム（-25°C安定化）
長期動作における画像品質の安定性を確保します。
主な仕様
IMX992 400-1700nm 1/1.4" SWIRカメラ
| モデル | 解像度 | フレームレート | ピクセルサイズ | インターフェース |
|---|---|---|---|---|
| iBX-SWG992A/J1 | 2560 × 2048 | 22fps | 3.45μm | GigE |
| iBX-SWTG992A | 2560 × 2048 | 165fps | 3.45μm | 10 GigE |
| iBX-SWU992J-Lite | 2560 × 2048 | 61.9fps | 3.45μm | USB 3.0 |
| iBX-SWU992A/J1 | 2560 × 2048 | 61.9fps | 3.45μm | USB 3.0 |
| iBX-SWC992A | 2560 × 2048 | 100fps | 3.45μm | Camera Link |
| iCt-SWX500S-Pro | 2592 × 2056 | 131.9fps | 3.45μm | CoaXPress |
注： A-TEC冷却 J-外部冷却
推奨アプリケーション
半導体ウェハ検査
材料分析
水分 & 欠陥検出
電子機器検査
科学イメージング
医薬品検査
食品品質管理
産業用自動化システム
2592x2056 SWIRエリアスキャンカメラ ダウンロード
