Q1: What is the Mars2000S-60gm used for?
A: It is a 2MP industrial machine vision camera designed for applications such as defect detection, surface inspection, robot guidance, and automated optical inspection (AOI).
Q2: What sensor does this camera use?
A: The camera uses the Sony IMX430 global shutter CMOS sensor, ensuring distortion-free imaging of fast-moving objects.
Q3: What is the resolution and frame rate?
A: It provides a resolution of 1624 × 1240 (2MP) with a maximum frame rate of up to 56 fps.
Q4: What interface does it support?
A: It supports a GigE interface with transmission distances up to 100 meters, and includes Power over Ethernet (PoE) support.
Q5: Is this camera suitable for high-speed inspection?
A: Yes, its global shutter sensor and high frame rate (56 fps) make it ideal for fast-moving industrial inspection tasks.
Q6: Does it support trigger modes?
A: Yes, it supports hardware trigger, software trigger, and free-run modes, allowing flexible synchronization with industrial systems.
Q7: What software and systems is it compatible with?
A: It is fully compatible with GigE Vision and GenICam standards, and supports Windows and Linux operating systems.
Q8: What are its physical characteristics?
A: The camera features a compact 29 × 29 × 42 mm design with a C-Mount lens interface, making it easy to integrate into tight industrial setups.
Q9: What industries commonly use this camera?
A: It is widely used in factory automation, logistics sorting, robotics, AOI systems, barcode reading, and precision measurement applications.
Estimated Delivery Time
Ship To Detecting...
?
Shipping dates are estimates and subject to change. By ordering, you accept possible schedule adjustments. For urgent orders, please confirm with us before purchasing. Post-order cancellations are subject to a 6.4% handling fee.
Descripción
Descripción del producto
El Mars2000S-60gm es una cámara de visión industrial compacta de 2MP diseñada para aplicaciones de inspección industrial de alta velocidad y alta precisión. Equipada con el sensor CMOS de obturador global Sony IMX430, ofrece una resolución de 1624 × 1240 píxeles a hasta 56 fps, garantizando imágenes sin distorsión para objetos en movimiento. Con una interfaz GigE con distancias de transmisión de hasta 100 metros y soporte para PoE, la cámara ofrece una fácil integración en sistemas de visión industrial. Es totalmente compatible con los estándares GigE Vision y GenICam y compatible con software de visión de terceros en plataformas Windows y Linux.
Características principales
- Sensor CMOS de obturador global Sony IMX430
- Resolución de 2MP (1624 × 1240)
- Adquisición de imágenes de alta velocidad de hasta 56 fps
- Tamaño de píxel de 4,5 μm para una excelente calidad de imagen
- Interfaz GigE con distancia de transmisión de 100 m
- Soporta Power over Ethernet (PoE)
- Modos de disparo por hardware, disparo por software y ejecución libre
- Memoria a bordo de 64 MB para transmisión en ráfaga y retransmisión
- Salida de imagen de 12 bits para imágenes de alto rango dinámico
- Tamaño compacto: 29 × 29 × 42 mm
- Interfaz de lente C-Mount
- Compatible con los estándares GigE Vision y GenICam
- Soporta sistemas operativos Windows y Linux
Aplicaciones típicas
- Detección de defectos
- Inspección de superficies
- Posicionamiento visual
- Medición de precisión
- Lectura de códigos de barras y códigos QR
- Inspección óptica automatizada (AOI)
- Guía de robots
- Automatización de fábrica
- Sistemas de logística y clasificación
- Sistemas de visión VR/AR
Parámetros del producto
| Número de modelo |
Mars2000s-60GM Modelo mejorado - iCt90MG20A-Pro |
| Resolución | 1624 px x 1240 px |
| Tamaño de píxel | 4,5 μm x 4,5 μm |
| Tasa de fotogramas | 56 fps |
| Mono/Color | Mono |
| Sensor | Sony IMX430 |
| Obturador | Obturador global |
| Tamaño del sensor | 1/1.7" |
| Tipo de sensor | CMOS |
| Tiempo de exposición | 26μs ~1s |
| Interfaz | GigE |
| Formato de imagen | Mono8/10/10packed |
| Sincronización | Mediante disparo por hardware, disparo por software o modo de ejecución libre |
| E/S digital |
Entrada optoaislada x 1, salida optoaislada x 1 y E/S personalizada bidireccional no aislada x 1 |
| Alimentación | CC 6-24V, con soporte para PoE |
| Consumo de energía | 12V @≈3.4W |
| Dimensiones (L x A x H) | 29.0 × 29.0 × 42.0 mm (88g) |
| Montura de lente | C-mount (CS-Mount puede personalizarse) |
| Temperatura de funcionamiento | -30 - 70°C (Almacenamiento), 0 - 50°C (Funcionamiento) |
| Controlador | Suite de software de cámaras de la serie Mars (iCentral) o Software GigE Vision de terceros |
| Sistema operativo | Windows, Linux |
| Conformidad | GigE Vision y GenICam |
Lista de embalaje
Dibujo de dimensiones (mm)
Hoja de datos MARS2000S-60GM&Descarga del manual
