Descripción
Product Parameters
| Series | Mars |
| Resolution | 5472 px x 3648 px |
| Pixel size | 2.4 μm x 2.4 μm |
| Frame Rate | 18 fps |
| Mono/Color | Mono and Color |
| Sensor Vendor | Sony |
| Sensor | IMX 183 |
| Shutter | Rolling Shutter |
| Sensor Size | 1" |
| Sensor Type | CMOS |
| Interface | USB 3.0 |
| Pixel Bit Depth | 8 / 10 bits |
| Synchronization |
● Soft Trigger ● Hardware Trigger ● Free Run
|
| I/O | Opto-isolated input x 1, opto-isolated output x 1, and bi-directional custom non-isolated I/O x 1 |
| Power Supply | USB3.0 / 3.0W |
| Design | Compact industrial design |
| Dimension (L x W x H) | 29 mm x 29 mm x 29 mm |
| Lens Mount | C-mount （CS-Mount can be customized ） |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） |
| Weight（Typical） | 60g |
| Driver , SDK | Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with USB3 Vision Protocol |
| Operating System | Windows，Linux |
| Conformity | USB3 Vision and GenICam |
Packing List
MARS5470S-18UM/UC Download
