Product Description
The Mars1300P-90GM/GC is a high-performance 1.3MP GigE Vision industrial camera designed for fast and precise machine vision applications. It delivers stable imaging at 90 fps with 1280 × 1024 resolution, making it ideal for high-speed inspection and automation systems.
With a compact design and reliable GigE interface, it ensures seamless integration into industrial environments requiring consistent and accurate image capture.
Key Features
- 1.3MP resolution (1280 × 1024) high-quality imaging
- High speed up to 90 fps
- GigE Vision interface for stable data transmission
- Compact design for easy system integration
- Optimized for industrial automation and inspection
Applications
Ideal for:
- Industrial automation
- High-speed inspection
- Electronics manufacturing
- Motion analysis
- Machine vision systems
Product Parameters
| Series | Mars |
| Resolution | 1280 px x 1024 px |
| Pixel size | 4.8 μm x 4.8 μm |
| Frame Rate | 90 fps |
| Mono/Color | Mono and Color |
| Sensor Vendor | ON Semiconductor |
| Sensor | PYTHON 1300 |
| Shutter | Global Shutter |
| Sensor Size | 1/2" |
| Sensor Type | CMOS |
| Dynamic range | 60.0 dB |
| Interface | GigE |
| Pixel Bit Depth | 8 / 10 bits |
| Synchronization | Soft Trigger,Hardware Trigger,Free Run |
| I/O | Opto-isolated input x 1, opto-isolated output x 1, and bi-directional custom non-isolated I/O x 1 |
| Power Supply | PoE or 6-24 VDC |
| Design | Compact industrial design |
| Dimension (L x W x H) | 42 mm x 29 mm x 29 mm |
| Lens Mount | C-mount （CS-Mount can be customized ） |
| Working Temperature | -30 - 50°C（Working），-30 - 80°C（Storage） |
| Weight（Typical） | 88g |
| Driver , SDK | Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with GigE Vision Protocol |
| Operating System | Windows，Linux |
| Conformity | GigE Vision and GenICam |
Packing List
MARS1300P-90GM/GC Download
