Q1: What is the LEO2 5470S-6GM/GC-Lite used for?
A: It is designed for logistics automation, barcode reading, package sorting, and industrial machine vision inspection requiring high-resolution imaging.
Q2: What sensor does this camera use?
A: The camera uses a Sony IMX183 20MP CMOS sensor with a resolution of 5472 × 3648 pixels.
Q3: What interface does the camera support?
A: It supports GigE Vision interface with PoE power supply, enabling long-distance and stable data transmission.
Q4: Is this camera suitable for fast-moving production lines?
A: Yes, it supports multiple trigger modes including hardware trigger, software trigger, and free run, making it suitable for automated production environments.
Q5: What is the working temperature range?
A: The camera operates from -30°C to 60°C, suitable for harsh industrial environments.
Q6: Is it compatible with third-party software?
A: Yes, it is fully compatible with GigE Vision and GenICam standards, and supports Windows and Linux systems.
Q7: What are the physical dimensions of the camera?
A: The compact body measures 29 × 29 × 42 mm and weighs approximately 100 g.
Q8: What industries commonly use this camera?
A: It is widely used in logistics, warehouse automation, barcode inspection, electronics manufacturing, and industrial quality control.
Estimated Delivery Time
Ship To Detecting...
?
Shipping dates are estimates and subject to change. By ordering, you accept possible schedule adjustments. For urgent orders, please confirm with us before purchasing. Post-order cancellations are subject to a 6.4% handling fee.
Description
![]()
Descrição do Produto
Câmera GigE Vision de 20MP para Automação Logística e Visão Computacional de Alta Resolução
A LEO2 5470S-6GM/GC-Lite é uma câmera industrial compacta de 20MP GigE Vision alimentada pelo sensor CMOS Sony IMX183. Com resolução de 5472 × 3648 a 5,9 fps, captura imagens de alto detalhe para leitura de códigos de barras, triagem de pacotes, inspeção de qualidade e aplicações de visão computacional de precisão.
Com um sensor de obturador rolante de 1 polegada, interface GigE com suporte a PoE e compatibilidade com os padrões GigE Vision e GenICam, a câmera integra-se perfeitamente em sistemas de automação industrial. O seu alojamento compacto de 29 × 29 × 42 mm e o design leve de 100 g facilitam a instalação, mesmo em equipamentos com espaço limitado.
Com suporte a saída de imagem de 8/10/12 bits, múltiplos modos de disparo, sistemas operativos Windows e Linux e o SDK iDatum, a Série LEO2 oferece desempenho fiável para ambientes de logística, manufatura e inspeção industrial.
Principais Características
✔ Sensor CMOS Sony IMX183 de 20MP
Resolução ultra-alta de 5472 × 3648 para captura de imagens detalhadas.
✔ Interface GigE Vision com PoE
Transmissão de imagem de longa distância fiável e instalação simplificada.
✔ Design Industrial Compacto
Alojamento de 29 × 29 × 42 mm para fácil integração no sistema.
✔ Múltiplos Modos de Disparo
Suporta Free Run, Disparo por Software e Disparo por Hardware.
✔ Fiabilidade Industrial
Funciona de -30°C a 60°C para ambientes exigentes.
✔ GigE Vision & Compatível com GenICam
Compatível com software e SDKs de visão computacional mainstream.
Aplicações Ideais
- Automação Logística
- Código de Barras & Leitura de Código QR
- Sistemas de Triagem de Pacotes
- Automação de Armazéns
- Inspeção de Qualidade Industrial
- Inspeção de Eletrónica
- Integração de Visão Computacional
- Linhas de Produção Automatizadas
Especificações do Produto
| Modelo | LEO2 5470S-6GM/GC-Lite |
| Resolução | 5472 px x 3468 px |
| Tamanho do Pixel | 2,4 μm x 2,4 μm |
| Taxa de Quadros | 5,9 fps |
| Mono/Cor | Mono e Cor |
| Fabricante do Sensor | Sony |
| Sensor | IMX183 |
| Obturador | Obturador Rolante |
| Tamanho do Sensor | 1" |
| Tipo de Sensor | CMOS |
| Interface | GigE |
| Profundidade de Bits do Pixel | 8 / 10 / 12 bits |
| Sincronização |
● Disparo por Software ● Disparo por Hardware ● Free Run |
| E/S | Entrada optoisolada x 1, saída optoisolada x 1 e E/S personalizada bidirecional não isolada x 1 |
| Alimentação | Alimentação PoE / 9-24 VDC |
| Design | Design industrial compacto |
| Dimensões (C x L x A) | 29 mm x 29 mm x 42 mm |
| Baioneta da Lente | C-mount |
| Temperatura de Funcionamento | -30 - 60°C (Funcionamento),-30 - 70°C (Armazenamento) |
| Peso (Típico) | 100g |
| Driver, SDK | Kit de Desenvolvimento Secundário de Câmeras da Série LEO (iDatum) ou Software de Terceiros compatível com o Protocolo GigE Vision |
| Sistema Operativo | Windows, Linux |
| Conformidade | GigE Vision e GenICam |
Lista de Embalagem
Download do Documento LEO2 5470S-6GM/GC-Lite
