Description
MARS720S-300GM/GC is a high-performance 1/2.9" area scan camera offering 0.4MP resolution and remarkable 300FPS frame rate. It supports GenICam and GigE Vision protocols, making it suitable for various image processing applications. The camera is compatible with HALCON, Vision Pro, and LabVIEW, and can seamlessly integrate with NVIDIA TX1, TX2, Windows, and Mac systems, providing flexibility for diverse use cases and industries.
Product Parameters
| Series | Mars |
| Resolution | 720 px x 540 px |
| Pixel size | 6.9 μm x 6.9 μm |
| Frame Rate | 300 fps |
| Mono/Color | Mono and Color |
| Sensor Vendor | Sony |
| Sensor | IMX 287 |
| Shutter | Global Shutter |
| Sensor Size | 1/2.9" |
| Sensor Type | CMOS |
| Dynamic range | 70.0 dB |
| Signal-to-Noise Ratio (typical) | >38.0 dB |
| Interface | GigE |
| Pixel Bit Depth | 8 / 10 / 12 bits |
| Synchronization | Soft Trigger,Hardware Trigger,Free Run |
| I/O | 1 input(opto-isolated)，1 output(opto-isolated),1 configurable input and output(without opto-isolated) |
| Power Supply | PoE or 6-24 VDC |
| Design | Compact industrial design |
| Dimension (L x W x H) | 42 mm x 29 mm x 29 mm |
| Lens Mount | C-mount （CS-Mount can be customized） |
| Working Temperature | -30 - 50°C（Operating），-30 - 80°C（Storage） |
| Weight（Typical） | 88g |
| Driver , SDK | Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with GigE Vision Protocol |
| Operating System | Windows，Linux |
| Conformity | GigE Vision and GenICam |
Packing List
MARS720S-300GM/GC Download
