Q1: What is the iBX-992 SWIR camera used for?
A: It is designed for industrial SWIR imaging applications, including semiconductor inspection, material analysis, moisture detection, and scientific research.
Q2: What is the spectral range of this camera?
A: The camera operates in the 400–1700nm SWIR range, with an optional extension up to 1800nm using filters.
Q3: What is the maximum frame rate?
A: It delivers up to 165fps at 2560×2048 resolution, enabling high-speed imaging for dynamic inspection tasks.
Q4: Does the camera support global shutter?
A: Yes, it uses a global shutter sensor, ensuring distortion-free imaging of fast-moving objects.
Q5: What interface options are available?
A: The iBX-992 supports USB 3.0, GigE Vision, and CameraLink interfaces, allowing flexible system integration.
Q6: What cooling system is used?
A: It features TEC (Thermoelectric Cooling) that stabilizes the sensor temperature up to 25°C below ambient.
Q7: Is it suitable for low-light or invisible imaging?
A: Yes, the SWIR range allows detection of features invisible to the human eye, ideal for defect and material inspection.
Q8: What industries use this camera most?
A: It is widely used in semiconductor, electronics, photovoltaics, food inspection, and scientific imaging industries.
Estimated Delivery Time
Ship To Detecting...
?
Shipping dates are estimates and subject to change. By ordering, you accept possible schedule adjustments. For urgent orders, please confirm with us before purchasing. Post-order cancellations are subject to a 6.4% handling fee.
Descrizione
Descrizione del prodotto
Fotocamera industriale SWIR ad alta velocità per ispezione avanzata dei materiali e imaging scientifico
La fotocamera industriale SWIR della serie iBX-992 è un sistema di imaging infrarosso a onde corte ad alte prestazioni, progettato per ispezioni industriali esigenti, analisi dei semiconduttori e applicazioni scientifiche.
Dotata di un sensore InGaAs da 1/1,4” e di un intervallo di risposta spettrale da 400–1700nm (opzionale fino a 1800nm), offre una sensibilità eccezionale sia per l'imaging visibile che per quello infrarosso. Con una risoluzione di 2560 × 2048 e una frequenza di aggiornamento fino a 165fps, la fotocamera garantisce acquisizioni ad alta velocità e alta risoluzione per attività di ispezione di oggetti in rapido movimento.
Supportando la tecnologia global shutter, l'imaging con gamma dinamica a 12 bit e un funzionamento stabile da -20°C a 60°C, la iBX-992 assicura un imaging accurato e privo di distorsioni in ambienti severi.
Le sue flessibili opzioni di connettività, tra cui USB 3.0, GigE Vision e CameraLink, la rendono altamente adattabile a diverse architetture di sistemi di visione artificiale. La tecnologia di raffreddamento TEC integrata mantiene la temperatura del sensore fino a 25°C sotto quella ambiente, garantendo la stabilità dell'imaging a lungo termine.
Caratteristiche principali
✔ Sensore InGaAs ad alta sensibilità da 1/1,4”
Ottimizzato per l'imaging SWIR da 400–1700nm.
✔ Imaging ad alta risoluzione 2560 × 2048
Offre dettagli fini per attività di ispezione di precisione.
✔ Prestazioni ad alta velocità fino a 165fps
Ideale per applicazioni industriali e scientifiche in rapido movimento.
✔ Tecnologia Global Shutter
Garantisce un imaging privo di distorsioni di scene dinamiche.
✔ Supporto multi-interfaccia
Compatibilità USB 3.0 / GigE Vision / CameraLink.
✔ Sistema di raffreddamento TEC (stabilizzazione a -25°C)
Garantisce una qualità dell'immagine stabile in funzionamento a lungo termine.
Specifiche principali
Fotocamera SWIR IMX992 400-1700nm 1/1,4"
| Modello | Risoluzione | Frequenza di aggiornamento | Dimensione del pixel | Interfaccia |
|---|---|---|---|---|
| iBX-SWG992A/J1 | 2560 × 2048 | 22fps | 3.45μm | GigE |
| iBX-SWTG992A | 2560 × 2048 | 165fps | 3.45μm | 10 GigE |
| iBX-SWU992J-Lite | 2560 × 2048 | 61.9fps | 3.45μm | USB 3.0 |
| iBX-SWU992A/J1 | 2560 × 2048 | 61.9fps | 3.45μm | USB 3.0 |
| iBX-SWC992A | 2560 × 2048 | 100fps | 3.45μm | Camera Link |
| iCt-SWX500S-Pro | 2592 × 2056 | 131.9fps | 3.45μm | CoaXPress |
Nota: A-TEC Raffreddamento J-Raffreddamento esterno
Applicazioni ideali
Ispezione di wafer di semiconduttori
Analisi dei materiali
Umidità & Rilevamento difetti
Ispezione elettronica
Imaging scientifico
Ispezione farmaceutica
Controllo qualità alimentare
Sistemi di automazione industriale
Fotocamera SWIR Area Scan 2592x2056 Download
